With a sleek and compact design, the WISE Energy 400W Portable Panel is perfect for outdoor enthusiasts, adventurers, and anyone seeking reliable power sources off the grid.

Simply unfold the panel, place it in direct sunlight, and start harnessing clean and renewable energy in seconds.

Note a solar MPPT is required. For the below voltages recommended MPPTs are;
12v System - Victron SmartSolar 100/30
24v System - Victron SmartSolar 100/15
48v System - Victron SmartSolar 100/20

Specifications
Cell Type                                                        Monocrystalline
Rated Power (W)                                          100 x 4 = 400 total
Open Circuit Voltage – Voc (V)                   21.2 each
Maximum Power Voltage – VMP (V)         18.0 each
Short Circuit Current (A) – ISC (A)              6.48 each
Maximum Power Current – IMP (A)          6.12 each
Maximum System Voltage (V)                    200
Power Tolerance                                           -3% / +10%
Dimensions –
Unfolded -1035 x 550 x 21mm per Panel (x4)
Unfolded Total – 1035 x 2200 x 21mm
Weight 13.2kg Total.

New IP65 rated 51.2V 200Ah Prismatic 4S1P LFP battery. Completely Victron compatible, available on display in Unanderra

This contact fits almost every Schneider part. Please see datasheet below for reference.

https://download.schneider-electric.com/files?p_enDocType=Instruction+sheet&p_File_Name=NNZ4314501-02.pdf&p_Doc_Ref=NNZ4314501

WISE - Ranger20
WISE Manufactured Cabinet (IP55 Rated) – Indoor/outdoor.
Victron 48/6000 Multi RS Inverter / Charger
The above has (2) 450V MPPT solar trackers
Victron Smart Shunt.
Victron Cerbo (Note Ekrano is no longer on front)
AC/DC Distribution
Programming as required.
Generator Input
230v AC Output.
1x 51.2v SafeBatt 5kw/h – Lithium Batteries

Optional Solar Kit Includes:
- Solar Panels, Flat Railing for Tin Roof, 15m Cabling, MC4 Connectors, MC4 Crimpers, Dektite, Stainless Ties, label kit, Length of conduit and associated expected glands.

Welder isolation switch 1Pole 300 Amp @ 30% duty. Male mech connectors on line side of switch, Female mech connectors on load side.

The ultimate LiFePO4 battery for seamless on and off-grid applications. With 300Ah capacity and operating at 12.8V, its prismatic cell design allows for individual monitoring, ensuring precise management of energy usage for optimal performance.

The SafeBatt Liter model contains a 200A BMS.

All SafeBatt batteries are built using over specified cells, raising the low voltage cut off to allow for rated capacity without over stressing cells, further increasing lifespan and reliability.

Warranty is 5years.

The ultimate LFP battery for seamless on and off-grid applications. With 100Ah capacity and operating at 51.2V, its prismatic cell design allows for individual monitoring, ensuring precise management of energy usage for optimal performance.

The EconoMAX entry level complete system for small installations.

It is fitted with
- Victron Pheonix 12/1200 Inverter - Converts the battery energy to 230V for running appliances
- Victron BlueSmart 12/30 Charger - Allows connection of a generator or external power source to charge
- Victron SmartSolar 100/30 - Coverts solar input to battery for charging
- Victron SmartShunt 500A - This measures your state of charge to monitor battery level
- All DC circuits breakers - Including 1x spare for connection of future hardwire 12v appliances
- Anderson connection to connect battery
- MC4 connectors for solar

This kit also comes packaged with;
2m Battery Cable Set
1x M and 1x F MC4 Connector for Solar

This would couple well with a single 415w solar panel and a LIFEP04 battery. If you need any advice on design or setup please feel free to call before purchasing

Note: Subject to Schneider availability mid 2024


PowerLogic AccuSine EVP+ is an active power correction solution for Electronic VAR Compensation / Static VAR Generator It is designed for Dynamic VAR Correction (PF correction) for industrial applications including mission critical environments. PowerLogic AccuSine EVP+ can also be configured for Harmonic Filtering and Network Unbalance Correction. The AccuSine EVC+ series can be used on a 208V to 480V network. VAR correction range : 1 kVar to 55 kVar at 208V network and 1 KVAR to 100 kVar at (380V to 480V) network. Includes a touchscreen HMI for configuration, commissioning and waveform capture. Connections include RS485 for Modbus protocol, and an USB port for firmware upgrades or reports. To be used by OEM (provided in an IP00 / UL open chassis) to be installed in a cabinet. To be used by OEM (IP00 / UL Type Open) chassis mount to be installed in a cabinet. The dimensions of the chassis are 1260mm in Height, 440mm in Width, 265mm in Depth, Weight 90kg. Certified for HCAI, CE, UKCA, RCM, UL, CSA and more, plus compliant with IEC 61439-1 and IEC 61439-2. Use M8 hardware to mount the unit in an enclosure. Remote management possible with EcoStruxure solution software. Avoid Power Factor Penalty, Improved Efficiency and Relibility, Reduced downtime. Up to 10 units can be paralleled, to achieve instantaneous VAR injection.

Note: Subject to Schneider availability mid 2024

This hardware is an active power correction solution, from AccuSine familly, to help stabilize electrical networks by providing harmonic mitigation and power factor correction, and load balancing. In addition to 3-phase mitigation, it has the ability to compensate for neutral harmonic currents. This version is UL Type OPEN, or ingress protection IP00, and can be connected on Low Voltage networks rated 208 Volt to 415 Volt. It is specified for a standard Root Mean Square output current rating of 60 Amps, 180 Amps neutral. The chassis is floor standing, allow cable entry from bottom and is delivered in RAL7035 light grey. This active power filter achieves above standards performance THDi less or equal to 3%, is certified to CE, IBC 2015, EAC, RCM. And is designed to IEC 62477-1, IEC 61000-6-2, IEC 61000-6-4 Class A, IEC 61439-1 and IEEE 519-2014. Up to 12 units in parallel per set of CT; any size unit combination possible (subject to network characteristics). Master capable. Frame exterior dimensions are 440 millimetres in width, 265 millimetres in depth, 960 millimetres in height and product weight 75 kg.

Welder emergency isolation switch 1Pole 600 Amp @ 30% duty. Supplied without connectors

32a 5PIN Mining Specification Extension Lead. Please note our leads are specific as they comply to AS3000 whereby dissimilar material or CSA conductors should not be paralleled and as a result the sheath is only earth at the origin

Made entirely here in Australia at our factory in Unanderra, an excellent solution to not mount on a combustible surface.

This Carlo Gavazzi Energy Meter is perfect for any site that needs CT metering for their Victron device and wants to be able to see both production and consumption.

Tested and working with Cerbo GX
