Non-polarity DC Isolator Switch.
DIN Mounting, Distribution Board, Door Clutch Mounting or
Plastic Enclosure optional.
Compact structure and modular design, levels with different Poles
from 2 to 8 are available.
Parallel connections design, more big bore diameter makes
connection fastness and flexibility.
Fast switching structure, arcing time normally occurs less than
3ms.
Self-cleaning contact mechanism, extending the lifespan of switch.
Dynamic sealing design and world class sealing materials
guarantee an IP66 protection rate.
UL94V-0 standard flame resistant materials , the product can be
full loading operation at temperatures -40 ℃ ~+70 ℃.
DC 1500V insulation voltage design, with TUV,
CE(IEC/EN60947-3:2009+A1+A2), SAA(AS60947.3), DC-PV1 and
DC-PV2. certifications.

This contact fits almost every Schneider part. Please see datasheet below for reference.

https://download.schneider-electric.com/files?p_enDocType=Instruction+sheet&p_File_Name=NNZ4314501-02.pdf&p_Doc_Ref=NNZ4314501

Welder isolation switch 1Pole 300 Amp @ 30% duty. Male mech connectors on line side of switch, Female mech connectors on load side.

Note: Subject to Schneider availability mid 2024


PowerLogic AccuSine EVP+ is an active power correction solution for Electronic VAR Compensation / Static VAR Generator It is designed for Dynamic VAR Correction (PF correction) for industrial applications including mission critical environments. PowerLogic AccuSine EVP+ can also be configured for Harmonic Filtering and Network Unbalance Correction. The AccuSine EVC+ series can be used on a 208V to 480V network. VAR correction range : 1 kVar to 55 kVar at 208V network and 1 KVAR to 100 kVar at (380V to 480V) network. Includes a touchscreen HMI for configuration, commissioning and waveform capture. Connections include RS485 for Modbus protocol, and an USB port for firmware upgrades or reports. To be used by OEM (provided in an IP00 / UL open chassis) to be installed in a cabinet. To be used by OEM (IP00 / UL Type Open) chassis mount to be installed in a cabinet. The dimensions of the chassis are 1260mm in Height, 440mm in Width, 265mm in Depth, Weight 90kg. Certified for HCAI, CE, UKCA, RCM, UL, CSA and more, plus compliant with IEC 61439-1 and IEC 61439-2. Use M8 hardware to mount the unit in an enclosure. Remote management possible with EcoStruxure solution software. Avoid Power Factor Penalty, Improved Efficiency and Relibility, Reduced downtime. Up to 10 units can be paralleled, to achieve instantaneous VAR injection.

Note: Subject to Schneider availability mid 2024

This hardware is an active power correction solution, from AccuSine familly, to help stabilize electrical networks by providing harmonic mitigation and power factor correction, and load balancing. In addition to 3-phase mitigation, it has the ability to compensate for neutral harmonic currents. This version is UL Type OPEN, or ingress protection IP00, and can be connected on Low Voltage networks rated 208 Volt to 415 Volt. It is specified for a standard Root Mean Square output current rating of 60 Amps, 180 Amps neutral. The chassis is floor standing, allow cable entry from bottom and is delivered in RAL7035 light grey. This active power filter achieves above standards performance THDi less or equal to 3%, is certified to CE, IBC 2015, EAC, RCM. And is designed to IEC 62477-1, IEC 61000-6-2, IEC 61000-6-4 Class A, IEC 61439-1 and IEEE 519-2014. Up to 12 units in parallel per set of CT; any size unit combination possible (subject to network characteristics). Master capable. Frame exterior dimensions are 440 millimetres in width, 265 millimetres in depth, 960 millimetres in height and product weight 75 kg.

Welder emergency isolation switch 1Pole 600 Amp @ 30% duty. Supplied without connectors
